Specifications
Parameter
Value
Format
Prismatic
Energy Density
164.43
Wh/kg
Type
LFP
Nominal Capacity
102
Ah
Nominal Voltage
3.2
V
Internal Resistance (min)
0.16
mΩ
Internal Resistance (max)
0.36
mΩ
Life Cycle
5000
cycles
Dimensions (W x H x T)
160 x 118.5 x 50.1
mm
Weight
1.985
kg
Shipping Classification
UN3480
Operating Conditions
Parameter
Value
Max Charging Current
1
C
Max Discharging Current
1
C
Charging Cut-off Voltage
3.65
V
Discharging Cut-off Voltage
2.5
V
Recommended SoC Window
10
% ~
90
%
Charging Temperature
0
°C ~
65
°C
Discharging Temperature
-20
°C ~
65
°C
Storage Temp (1 month)
-20
°C ~
45
°C
Storage Temp (1 year)
15
°C ~
35
°C
Applications
ESS-Big/GridSupport
ESS-Small
ESS-Solar & Wind
ESS-Telecom (UPS)
EV-Boats
EV-Cars, Motorcycles, Bikes
EV-Public Transport
EV-Retrofit
EV-Utility/Industrial Vehicles
Aluminium shell for better cooling.
Anti-explosion safety valve applied.
